Bell 206

The Bell 206 is a family of two-bladed, single- and twin-engined helicopters, manufactured by Bell Helicopter at its Mirabel, Quebec plant.
The Bell 206 Helicopter is one of the most successful and safest helicopters ever built. With a great power to weight ratio, it is a great option for groups.

General information

39.2’
LENGTH
10.8’
Height
260 NM
Range
4
PASSENGERS
3 Hours 40 M
Endurance
105 knots
Max Speed

KEY SPECIFICATIONS OF Bell 206

The Bell 206 helicopter is a versatile aircraft designed for both utility and passenger transport.

With a crew capacity of one pilot and the ability to carry up to four passengers, it offers a compact yet efficient means of aerial transportation.

The helicopter measures 39 feet 8 inches in length, with a rotor diameter of 33 feet 4 inches and a height of 9 feet 4 inches.

Powered by a single Allison 250-C20J turboshaft engine, which delivers 317 shp due to drivetrain limitations, the Bell 206 has a maximum takeoff weight of 3,200 pounds. It boasts a maximum speed of 120 knots and a range of 374 nautical miles, making it suitable for a variety of missions. With a service ceiling of 13,500 feet and a rate of climb of 1,350 feet per minute.

The Bell 206 is a reliable and capable aircraft for various aerial operations.



Capacity 4 Passengers
Rotor Diameter 33 ft 4 in (10.16 m)
Empty Weight 2,331 lb (1,057 kg)
Maximum Seating 1 + 6
Max. Takeoff Weight 3,200 lb (1,451 kg)
Powerplant 1 × Allison 250-C20J turboshaft, 420 shp
Power/Mass 0.26 hp/lb (430 W/kg)
